Rtd PT100-Tef/Tef-6*7/0.2 Thermocouple Wire
This specification covers the requirements for TEF insulated,TEF sheathed RTD extension cable, 6*24AWG, stranded wire.1.Stranded RTD extension wire: Conductors Size(AWG)NO.of Strands &Gauge247/0.2mm 2.Insulation:Extruded TEF ( 200ºC) Nominal Insulation Thickness 0.16mm&plus......
Send Inquiry
Product Description
This specification covers the requirements for TEF insulated,TEF sheathed RTD extension cable, 6*24AWG, stranded wire.
1.Stranded RTD extension wire:
| Conductors Size(AWG) | NO.of Strands &Gauge |
| 24 | 7/0.2mm |
2.Insulation:Extruded TEF ( 200ºC)
| Nominal Insulation Thickness | 0.16mm±0.2 |
| Color code | 4 cores red and 2 cores white |
3. Assembly:Six conductors (cores) twisted construction.
4. Overall JacketExtruded TEF ( 200ºC)
| Nominal Sheath Thickness | 0.38mm±0.2 |
| Color code | white |
| Dimensions/tolerances(mm) | Ø3.65±0.25 |
