Product Description

Multi-Conductor Type Soow, 600 Volt, UL /cUL Portable Cable 18AWG - 10AWG

CONSTRUCTION
Conductors: Bare, annealed copper per ASTM B-3 Flexible, bunch-stranded per UL-62
Separator: A paper tape is applied between the conductor and insulation to facilitate stripping.
Insulation: Color coded synthetic rubber (EPDM) oil and water resistant per UL-62
Jacket: Black Chlorinated Polyethylene (CPE)
Cabling: Conductors are assembled round with fillers as needed.
Temperature Range: -40°C to +90°C
Voltage Rating: 600 Volts for SOOW,300 Volts for SJOOW

Conductor Size (AWG)	Conductor Stranding			Nominal Insulation Thickness	Nominal Jacket Thickness	Nominal Overall Diameter (in)	Weight	Ampacity
Conductor Size (AWG)	n	/	AWG/inch	mil	mil	in	lbs/1000ft	A
2*18AWG	16	/	30	30	60	0.33	70	10
3*18AWG	16	/	30	30	60	0.35	80	10
4*18AWG	16	/	30	30	60	0.37	96	7
2*16AWG	26	/	30	30	60	0.36	86	13
3*16AWG	26	/	30	30	60	0.37	99	13
4*16AWG	26	/	30	30	60	0.41	119	10
2*14AWG	41	/	30	45	80	0.49	155	18
3*14AWG	41	/	30	45	80	0.51	179	18
4*14AWG	41	/	30	45	80	0.56	215	15
2*12AWG	65	/	30	45	95	0.56	206	25
3*12AWG	65	/	30	45	95	0.58	239	25
4*12AWG	65	/	30	45	95	0.63	290	20
2*10AWG	104	/	30	45	95	0.62	266	30
3*10AWG	104	/	30	45	95	0.66	316	30
4*10AWG	104	/	30	45	95	0.72	385	25
3*8AWG	133	/	29	60	110	0.83	505	40
4*8AWG	133	/	29	60	125	0.93	646	35
5*8AWG	133	/	29	60	125	0.93	684	35
3*6AWG	133	/	27	60	125	0.95	694	55
4*6AWG	133	/	27	60	140	1.07	885	45
5*6AWG	133	/	27	60	140	1.07	946	45
3*4AWG	133	/	0.0177	60	140	1.09	952	70
4*4AWG	133	/	0.0177	60	155	1.22	1210	60
5*4AWG	133	/	0.0177	60	155	1.22	1304	60
3*2AWG	133	/	0.0223	60	155	1.26	1344	95
4*2AWG	133	/	0.0223	60	170	1.41	1705	80
5*2AWG	133	/	0.0223	60	170	1.41	1853	80
