Fiber Glass Special Nickel Plated Copper Wire
Product dimensions:ConductorInsulationMax.cond resistance(Ω/km)Unit Length(m)(Ft)Size(AWG)Construction(No./mm)Diameter(mm)Nominal Thickness(mm)Diameter(mm)267/0.160.48 0.60 1.68 143305/1000247/0.200.61 1.81 89.3227/0.2540.77 1.97 56.4207/0.310.94 2.14 35.2187/0.391.19 2.39 22.2167/0.491.49......
Send Inquiry
Product Description
Product dimensions:
| Conductor | Insulation | Max.cond resistance (Ω/km) | Unit Length (m)(Ft) | |||
| Size (AWG) | Construction (No./mm) | Diameter (mm) | Nominal Thickness (mm) | Diameter (mm) | ||
| 26 | 7/0.16 | 0.48 | 0.60 | 1.68 | 143 | 305/1000 |
| 24 | 7/0.20 | 0.61 | 1.81 | 89.3 | ||
| 22 | 7/0.254 | 0.77 | 1.97 | 56.4 | ||
| 20 | 7/0.31 | 0.94 | 2.14 | 35.2 | ||
| 18 | 7/0.39 | 1.19 | 2.39 | 22.2 | ||
| 16 | 7/0.49 | 1.49 | 2.69 | 14 | ||
| 24 | 1/0.50 | 0.50 | 0.65 | 1.80 | 89.3 | 305/1000 |
| 22 | 1/0.65 | 0.65 | 1.95 | 56.4 | ||
| 20 | 1/0.81 | 0.81 | 2.11 | 35.2 | ||
| 18 | 1/1.02 | 1.02 | 2.32 | 22.2 | ||
| 16 | 1/1.20 | 1.20 | 2.50 | 14 | ||
| 24 | 11/0.16 | 0.61 | 0.60 | 1.81 | 89.3 | 305/1000 |
| 22 | 17/0.16 | 0.76 | 1.96 | 56.4 | ||
| 20 | 26/0.16 | 0.94 | 2.14 | 35.2 | ||
| 18 | 41/0.16 | 1.18 | 2.38 | 22.2 | ||
| 16 | 26/0.254 | 1.49 | 2.69 | 14 | ||
| 0.30mm² | 12/0.18 | 0.71 | 0.60 | 1.91 | 59.78 | 305/1000 |
| 0.50mm² | 20/0.18 | 0.92 | 2.12 | 40.1 | ||
| 0.75mm² | 30/0.18 | 1.13 | 2.33 | 26.7 | ||
| 1.00mm² | 40/0.18 | 1.31 | 2.51 | 20 | ||
| 1.25mm² | 50/0.18 | 1.46 | 2.66 | 14.35 | ||
Service
Shipment:
1. by express
2. by sea
Payment terms:
LC, TT, Western Union, Money Gram and PayPal
Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days
