Electrical Cable 90c XLPE Wire UL3320
Product dimensions:ConductorInsulationMax.cond resistance(Ω/km)Unit Length(m)(Ft)Size(AWG)Construction(No./mm)Diameter(mm)Nominal Thickness(mm)Diameter(mm)307/0.100.30 0.781.86 361305/1000287/0.1270.38 1.94 227267/0.160.48 2.04 1432411/0.160.60 2.16 89.32217/0.160.76 2.32 56.42021/0.180.94......
Send Inquiry
Product Description
Product dimensions:
| Conductor | Insulation | Max.cond resistance (Ω/km) | Unit Length (m)(Ft) | |||
| Size (AWG) | Construction (No./mm) | Diameter (mm) | Nominal Thickness (mm) | Diameter (mm) | ||
| 30 | 7/0.10 | 0.30 | 0.78 | 1.86 | 361 | 305/1000 |
| 28 | 7/0.127 | 0.38 | 1.94 | 227 | ||
| 26 | 7/0.16 | 0.48 | 2.04 | 143 | ||
| 24 | 11/0.16 | 0.60 | 2.16 | 89.3 | ||
| 22 | 17/0.16 | 0.76 | 2.32 | 56.4 | ||
| 20 | 21/0.18 | 0.94 | 2.49 | 35.2 | ||
| 18 | 16/0.254 | 1.18 | 2.73 | 22.2 | ||
| 16 | 26/0.254 | 1.50 | 3.06 | 14 | ||
| 14 | 41/0.254 | 1.89 | 3.45 | 8.78 | ||
| 12 | 65/0.254 | 2.37 | 3.93 | 5.53 | ||
| 10 | 105/0.254 | 3.02 | 4.58 | 3.476 | ||
| 9 | 133/0.254 | 3.36 | 4.92 | 2.73 | ||
| 8 | 133/0.28 | 3.75 | 1.15 | 6.05 | 2.16 | 100/328 |
| 7 | 65/0.45 | 4.21 | 1.53 | 7.27 | 1.716 | |
| 6 | 84/0.45 | 4.79 | 7.85 | 1.361 | ||
| 4 | 133/0.45 | 6.02 | 9.08 | 0.8559 | ||
| 2 | 212/0.45 | 7.60 | 10.66 | 0.5384 | ||
Service
Shipment:
1. by express
2. by sea
Payment terms:
LC, TT, Western Union, Money Gram and PayPal
Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days
