Indoor Use UTP Cat5e Cable/LAN Cable/Network Cable

LAN CABLE UTP CAT5e
1. UTP/FTP/STP/SFTP
2.24awg
3.100MHz bandwidth
4.305m/roll
5. Pass FLUKE TEST
Packing information:
1. Packing
TypeLengthCarton sizeQTYG. W.
Cat6A
100m 57x43x30cm 5 roll15kg
305m 75x38x48cm 4 roll35kg
500m 38.5x38.5x30cm1 roll17kg


Introduction
What is cat6A cable?
CAT6 is an Ethernet cable standard defined by the Electronic Industries Association and Telecommunications Industry Association (commonly known as EIA/TIA). CAT6A is the sixth generation of twisted pair Ethernet cabling.

Specification
Conductor: CU, CCA, CCS, CCAM
Insulation: HDPE(Polyethylene)
Outside Diameter: 6.22m+/-0.2mm
Construction:
Conductor
23AWG(0.50mm+/-0.02mm)BC/CCA/CCS/CCAM
Insulation
1.02mm+/-0.02mmPE/HDPE
Pairs
4 pairs
Ripcord
Yes
Sheath
6.26mm+/-0.2mmPVC/LSZH
Color
Gery, black, white, blue, red or as client's request
Application
1. Computer Network Cabling Project
2. Broadband Network Communication
3. Digital ISND Network and ATM 125Mbps Network
4. Ethernet Network
5. Audio and Data Transmission
6. Trunk Wiring
7. Noisy Enviroment

Electrical Specfications
Dielectric strength
2.5kv dc-2seconds
Conductor resistance
Max 9.38ohm/100mt at 20° C
Max ring resistance
16.8ohm/100mt at 20° C
Max mutual capacitance
560pf/100mt
Max capacity unbalance
330pf/100mt
Impedance
100+/-15% at 1~100MHz

Packaging & Shipping

Packing Details
1)Packing length: 305m/roll, 500m/roll or as client's request.
2)Inner packing: Easy pull box.
3)Outer packing: Carton box.
4)Other packing is available according client's request.
Delivery date
5-15days after confirmed.
